Height Gauge V1

Precision Scribing

Tailored for precision scribing applications in tough environments.

Bidirectional measurements

Advanced capabilities including diameters and centerline measurements without extra tools (V1+).

Robust Design

Engineered for durability, reliability, and easy transportability.

Operating comfort

A counterweight system provides unparalleled operational efficiency and comfort.

Enhanced Accuracy

Includes measuring force management for consistent precision (V1+).

Immediate Use Readiness

Very simple and intuitive operation. Clear and large display.

Tough gauges for the modern workshop

Price request

Demo request

Trimos SA is proud to present its latest entry-level vertical measuring instruments, the V1 and V1+.

In the evolving landscape of dimensional metrology, Trimos is proud to announce the launch of its latest innovations: the V1 and V1+. These entry-level instruments are masterfully designed to serve as the perfect bridge between the traditional world of scribers and the advanced realm of height gauges, embodying the Swiss commitment to precision, reliability, and user-friendly design.

V1: Ideal for those taking their first steps into precision measurement. The V1 simplifies unidirectional measurements and tracing with remarkable ease. It offers a seamless transition for users accustomed to manual scribers, upgrading their toolset without sacrificing simplicity and robustness. This instrument is crafted to endure, embodying the Swiss ethos of durability and precision, with features tailored for immediate application:

V1+ : This model takes the foundational qualities of the V1 to new heights, catering to those looking to broaden their measurement capabilities. It introduces bi-directional measurement, which brings added versatility without necessitating extra accessories. It also features advanced fine adjustment and a constant measuring force, both critical for improving measurement precision.

Robust and Easily Portable
Clear, Simple User Interface
Counterweight for Operational Comfort
Quick and Smooth Carriage movement
Designed and manufactured in Switzerland
Bidirectional Measurement Capability (V1+)
Measuring Force Management (V1+)
RS232 Connectivity (Bluetooth coming soon)
Available in 300 and 600 mm models

Extended Warranty

Related products

Height gauge V1 Height gauge V2 Height gauge V3 Height gauge V4 Height gauge V4+ Height gauge V5 Height gauge V6 Height gauge V8 Height gauge V7 Height gauge V9 What is a height gauge

Documentation

Brochure height gauge V1/V1+ Catalog Trimos height-gauges Accessories height gauges Technical specifications Video

Technical details

V1		300	600
Measuring range	mm (in)	306 (12)	611 (24)
Max permissible errors, B_MPE	mm	0.018	0.030
Repeatability, R_MPE (2s)	mm	0.010
Max. Resolutions	mm (in)	0.01 (0.001)
Measuring force	N	–
Autonomy	h	2000
Interfaces		RS232
Max. travel speed	mm/s	1500
Weight (steel base)	kg	7	8

V1+		300	600
Measuring range	mm (in)	306 (12)	611 (24)
Max permissible errors, B_MPE	mm	0.015	0.025
Repeatability, R_MPE (2s)	mm	0.005
Max. Resolutions	mm (in)	0.001 (0.0001)
Measuring force	N	3
Autonomy	h	2000
Interfaces		RS232
Max. travel speed	mm/s	1500
Weight (steel base)	kg	7	8
Weight (granite base)	kg	13.4	15

The above values were determined in accordance with ISO 13225 using the TA-MI-121 insert.
R_MPE is defined as 2 times the standard deviation (2s) over a series of 20 height measurements.
